The MW7IC3825NR1, MW7IC3825NBR1 and MW7IC3825GNR1 wideband integrated circuits are designed with on-chip matching that make them usable from 3400–3600 MHz. This multi-stage structure is rated for 26 to 32 Volt operation and covers all typical cellular base station modulations. View Product Image
Features
-
Typical WiMAX Performance: VDD = 28 Volts, IDQ1 = 130 mA, IDQ2 = 230 mA, Pout = 5 Watts Avg., f = 3600 MHz, OFDM 802.16d, 64 QAM 3/4, 4 Bursts, 10 MHz Channel Bandwidth, Input Signal PAR = 9.5 dB @ 0.01% Probability on CCDF.
-
Power Gain: 25 dB
-
Power Added Efficiency: 15%
-
Device Output Signal PAR: 8.5 dB @ 0.01% Probability on CCDF
-
ACPR @ 8.5 MHz Offset: –48 dBc in 1 MHz Channel Bandwidth
-
Typical WiMAX Performance: VDD = 28 Volts, IDQ1 = 190 mA, IDQ2 = 230 mA, Pout = 0.5 Watts Avg., f = 3400 and 3600 MHz, OFDM 802.16d, 64 QAM 3/4, 4 Bursts, 10 MHz Channel Bandwidth, Input Signal PAR = 9.5 dB @ 0.01% Probability on CCDF.
-
Power Gain: 23.5 dB
-
Power Added Efficiency: 3.5%
-
Device Output Signal PAR: 9.2 dB @ 0.01% Probability on CCDF
-
ACPR @ 8.5 MHz Offset: –55 dBc in 1 MHz Channel Bandwidth
-
Capable of Handling 10:1 VSWR, @ 32 Vdc, 3500 MHz, 25 Watts CW Output Power
-
Stable into a 5:1 VSWR. All Spurs Below –60 dBc @ 0 to 44 dBm CW Pout
-
Typical Pout @ 1 dB Compression Point ≃ 30 Watts CW
-
100% PAR Tested for Guaranteed Output Power Capability
-
Characterized with Series Equivalent Large–Signal Impedance Parameters and Common Source S-Parameters
-
On-Chip Matching (50 Ohm Input, DC Blocked)
-
Integrated Quiescent Current Temperature Compensation with Enable/Disable Function
-
Integrated ESD Protection
-
Greater Negative Gate-Source Voltage Range for Improved Class C Operation
-
225°C Capable Plastic Package
-
RoHS Compliant
-
In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.
